Three front air floating tables with blowers for easy & smooth feeding movement of work piece.
Powerful, precise and efficient high speed panel cutting.
With high feed rate driven by rack / pinion and guided on hard guide rods that ensures high cutting accuracy. Saw carriage Drive motor has variable feed speed for different applications.
Easy & fast changing of main saw and scoring saw blades.
Easy accessible user friendly control panel for easy & quick operations.
Fence is equipped with DRO that displays the job length digitally. This enables a setting precision accuracy of +/- 0.1 mm.
| Model No | Unit | J-280.in |
|---|---|---|
| Capacity | ||
| Maximum length of cut | mm | 2800 |
| Maximum depth of cut | mm | 60 |
| Main saw unit | ||
| Maximum blade diameter | mm | 300 |
| Arbor diameter | mm | 60 |
| RPM of main saw blade | rpm | 5000 |
| Main saw unit motor | hp | 10 |
| Scoring saw unit | ||
| Maximum blade diameter | mm | 150 |
| Arbor diameter | mm | 45 |
| RPM of scoring saw blade | rpm | 7500 |
| Saw carriage | ||
| Feed forward speed | m/min | 10 to 30 |
| Retract speed | m/min | 30 |
| Saw carriage motor | hp | 1 |
| Other Specifications | ||
| Diameter of dust extraction port | mm | 100 |
| Compressed air requirement | kg/cm² | 6 to 7 |
| Floating table blower total motors | hp | 2 |
| Total power | hp | 13 |
| Machine dimension (L × B × H) | mm | 5160 × 4110 × 1650 |
| Approx. net weight | kg | 2500 |
A very useful accessory. This pneumatic clamp allows more maneuverability in panel handling, sizing and cutting. Also quality cuts on irregular Panels or thin work pieces.
PC + (2.0) : 3 step Pneumatic Clamp: This 3 step clamp allows more flexibility for handling small pieces.
