Maximum cutting thickness up to 100 mm.
Heavy duty pneumatic suspension grippers
Pneumatic side aligner supplied as standard. It is integrated with saw carriage, to perfectly align panels.
Air floating table for smooth and easy board movement, suitable for heavy and big panels.
High precision automatic servo drive system
Label printer supplied as standard.
| Specifications | OptiCut 2.9 | OptiCut 3.3 |
|---|---|---|
| Max. cutting length | 2900 mm | 3300 mm |
| Max. cutting thickness | 100 mm | 100 mm |
| Saw carriage forward speed | 10 m/min | 10 m/min |
| Saw carriage backward speed | 10 m/min | 10 m/min |
| Main saw blade size | 400 × 75 mm | 400 × 75 mm |
| Speed of main saw blade | 4000 rpm | 4500 rpm |
| Main saw motor | 20 hp | 20 hp |
| Scoring saw blade size | 160 × 45 mm | 160 × 45 mm |
| Speed of scoring saw blade | 6500 rpm | 6500 rpm |
| Scoring saw motor | 3 hp | 3 hp |
| Auto feeding motor (AC servo) | 2.4 hp | 2.4 hp |
| Feeding speed | 10 m/min | 10 m/min |
| Saw carriage drive motor | 2.4 hp | 2.4 hp |
| High pressure blower motor | 3 hp | 3 hp |
| Working air pressure | 5–7 Kg/cm² | 5–7 Kg/cm² |
| Total power | 30.8 hp | 30.8 hp |
| Machine dimension (L × B × H) | 6650 × 5050 × 1850 mm | 7100 × 5560 × 1850 mm |
| Approx. weight | 3000 kg | 3500 kg |
